8SMC4-Ethernet/RS232-B19x3-8 - Multi-Achsen Motion Controller / Driver

Preis auf Anfrage



  • 644616700
8SMC4-Ethernet/RS232-B19x3-8 Multi-Axis Motion Controller / Driver Specifications... mehr
Produktinformationen "8SMC4-Ethernet/RS232-B19x3-8 - Multi-Achsen Motion Controller / Driver"

8SMC4-Ethernet/RS232-B19x3-8
Multi-Axis Motion Controller / Driver


Specifications

Number of axes8
Motor parameters
   Motor typestepper/dc/servo
   Current
      Stepper motor0,1- 3 A
      DC, servo0,1- 6 A
   Voltage2-36
Motor kinematics
   Step division (for stepper motor)1-1/256
   Maximum speed
      Stepper motor35000 steps/s
      DC, servo800000 counts/s
Motion control
   Motion modesmove left/right, move to point, shift on delta, continuous speed,
acceleration and deceleration ramps, backlash compensation mode,
automatic home position calibration mode,
linear interpolation, circular interpolation
   Control loopOpen loop, closed loop (PID regulation)
Compensation
   Backlash compensationIncluded
   Step loss compensationIncluded
Positioner sensors reading
   Encoder (linear, rotary)Incremental quadrature encoder
   Limit switchesoptron, hall sensor, microswitch
   Revolution sensorsupported
Communication interfaceEthernet, RS232
I/O
   SynchronizationI/O included
   Output+3V; +5V for power supplying
Motor connectorDB15F
Position counter40 bit
Positioner identificationOne-wire interface (for Standa positioners only)
ProtectionsESD protection, Current overload protection, Voltage overload protection,
Short circuit protection, Motor hot plug/unplug protection
Operating temperatureUp to 70 degrees C
LED indicationIncluded
ProgrammingC++, C#, .NET, Delphi, Visual Basic, gcc, Xcode, Matlab, Java, LabVIEW.
Power parameters
   Power supply100-240V, 50-60Hz, 10A
Dimensions483x398x143.3
