1VIS10W-075-09-77 - Pneumatic Vibration Isolation Workstation

Preis auf Anfrage



  • 644614727
  • 9031908590/LT
Height of the vibration isolation system 600, 700 mm Vertical movement range 14 mm... mehr
Produktinformationen "1VIS10W-075-09-77 - Pneumatic Vibration Isolation Workstation"
Height of the vibration isolation system 600, 700 mm
Vertical movement range 14 mm
Precision of automatic level control ±0.3 mm
Vertical resonance frequency 1.5 Hz (average load)
Vertical isolation at 5 Hz 85–93%
Vertical isolation at 10 Hz 90–98%
Horizontal resonance frequency 1.7 Hz (average load)
Horizontal isolation at 5 Hz 85–93%
Horizontal isolation at 10 Hz 90–97%
Pressure from source of air 600 KPa (6 bar) (87 PSI)
Air supply socket diameter Ø 6 mm
Operating humidity (max) 90%
Operating temperature range 10–50 ºC
Load-bearing capacity (at 6 bar) 120 kg per isolator

Including Armrest
Including Breadboard 750*900mm
