"Pl-convex Lens; 15mm; BK7; FL 30mm"
Nicht angegeben
Artikelnummer:
644614542
Warentarifnr.:
90019000/BG
Produktinformationen ""Pl-convex Lens; 15mm; BK7; FL 30mm""
Material: N-BK7
Dmr.: 15,0 mm +0/-0,1
CA > 14,00 mm
EFL: 30,0 mm +/-1% @587,6 nm
BFL: 27,90 mm @587,6 nm
R1 = 15,52 mm
ET: 1,25 mm
CT: 3.18 mm +/-0,1
Centricity: 3-5 min
SQ: 40-20 SD
Chamfers: 0,25 x 45
Uncoated
Dmr.: 15,0 mm +0/-0,1
CA > 14,00 mm
EFL: 30,0 mm +/-1% @587,6 nm
BFL: 27,90 mm @587,6 nm
R1 = 15,52 mm
ET: 1,25 mm
CT: 3.18 mm +/-0,1
Centricity: 3-5 min
SQ: 40-20 SD
Chamfers: 0,25 x 45
Uncoated
